Unlock the true potential of your RAW cinema camera with the Shogun Inferno. ProRes RAW at up to 5.7kp30, 4kp120 DCI/UHD and 2kp240 DCI/HD. Inferno is compatible with Sony FS series, Canon C300MKII/C500 or Panasonic EVA-1/Varicam LT.
Video from any camera or digital video source can be captured via SDI or HDMI. Record up to 10-bit 4:2:2 in ProRes or DNxHR codecs at 4Kp60 or 2Kp240, depending on the camera’s capability.
The 7” 1920x1200 1500nit high bright HDR display allows you to see your images even outside in daylight.
Included as Standard
Accessories
|
SDI Cable
HDMI Cable
|
| Power |
Mains Cable
Sony Batteries |
| Memory |
Minimum 240GB SSD & Reader |
Key Specs
Display
| Panel Type |
IPS-Type LCD |
| Display Size |
7.1" / 18.0 cm |
| Screen Resolution |
1920 x 1200 |
| Aspect Ratio |
16:9 |
| Touchscreen |
Yes |
| Maximum Brightness |
1500 cd/m2 |
| Bit Depth / Color Support |
8-Bit+FRC (1.07 Billion Colors) |
| Pixels Per Inch (ppi) |
325 ppi |
| Real-Time LUT Monitoring |
SDR |
I/O
| Video |
1 x HDMI Type A (HDMI 2.0) Output
1 x BNC (12G-SDI) Output
1 x HDMI Type A (HDMI 2.0) Input
4 x BNC (3G-SDI) Input |
| Embedded Audio |
HDMI: 8-Channel
SDI: 12-Channel |
| Audio |
1 x 3.5 mm Headphone Output
1 x 10-Pin LEMO Input/Output |
| Built-In Speaker |
None |
| Power |
1 x Barrel Input |
| Other I/O |
1 x Genlock/LTC (BNC)
1 x LANC (2.5 mm) |
| Card Slot |
None |
Format Support
| Video Format |
HDMI (8/10-Bit 4:2:2)
UHD 4K: 24/25/30/50/60
1080p: 24/25/30/50/60/120/240
1080i: 50/60
720p: 50/60
SDI (8/10-Bit 4:2:2)
DCI 4K: 24/25/30/50/60
1080p: 24/25/30/50/60/120
1080PsF: 24/25/30
1080i: 50/60
720p: 50/60 |
| Video Signal Conversion |
HDMI to SDI
UHD 4K: 24/25/30
1080p: 24/25/30/50/60/120
1080i: 50/60
720p: 50/60
SDI to HDMI
UHD 4K: 24/25/30
1080p: 24/25/30/50/60/120
1080i: 50/60
720p: 50/60 |
Recording
| Pulldown Conversion |
2:2, 3:2 |
| Camera Trigger |
SDI, HDMI |
| Encoding Formats |
4096 x 2160
ProRes Raw, Raw HQ, 422, LT, HQ at up to 60 fps
DNxHR HQ, HQX, SQ, LB at up to 60 fps
3840 x 2160
ProRes 422, LT, HQ at up to 60 fps
DNxHR HQ, HQX, SQ, LB at up to 60 fps
1920 x 1080
ProRes 422, LT, HQ at up to 240 fps
DNxHD 220x, 145, 36 at up to 240 fps |
| Phantom Power |
+48 V |
Power
| DC Input Power |
6.2 to 16.8 VDC |
| Battery Type |
2 x L-Series |
