Description
Overview
The Canon C200 is a great camera rental option for the single shooter. This camera has the same Canon colour science they have become famous for in a body and form factor familiar to run and gun camera operators.
We offer this camera with SD Cards as standard for normal MP4 recording or in a package with CFAST Media for RAW recording. This opens up greater flexibility and makes this a very capable camera for the price point.
We have been thrilled to see the results our customers have been getting in both the regular and RAW recording modes.
Included as Standard
| Power |
2 x BP-A60 Batteries & Single Charger |
| Media |
2 x 128 SD Cards (REGULAR PACKAGE) |
| Accessories |
Top Mic |
Key Specs
-
Sensor
Super 35mm type CMOS
System
RGB primary colour filter (Beyer array)
Total pixels per sensor
Approx. 9.84 megapixels (4206 x 2340)
Effective pixels per sensor
Approx. 8.85 megapixels (4096 x 2160): When 4096 x 2160 or 2048 x 1080 is selected as the resolution
Approx. 8.29 megapixels (3840 x 2160): When 3840 x 2160 or 1920 x 1080 is selected as the resolutionSignal-to Noise Ratio
50.00 Hz mode: 53 dB (Typical)
[3840x2160/25.00P, Canon Log 3 Base sensitivity ISO800 (Dynamic range 1600%),HDMI OUT]Dynamic Range
15 Stops (CinemaRAW Light)13 Stops (MP4/Canon Log3)
Image Processor
Type
Dual DIGIC DV6
Lens
Lens Mount
Canon EF Mount
Lens Magnification Factor (for EF Mount lenses, including Cinema Primes)
At 4096 x 2160 or 2048 x 1080 resolution: Actual focal length x approx. 1.460 At 3840 x 2160 or 1920 x 1080 resolution: Actual focal length x approx. 1.534
Changeable Lens Mount
Yes, mount change to PL mount possible via Canon Service centre (Paid for service)
Peripheral illumination correction
Yes with compatible lenses
ND filter
Clear,2,4,6,8,10-stop
Focus control
Manual via lens, manual via RC-V100 Auto Focus (Dual Pixel AF Approximately 80%(vert.),80%(horiz.))
Iris control
Manual Via camera body or RC-V100, fine, 1/2 or 1/3 step increments, Auto (with compatible lenses), Push Auto Iris
Image stabilization system
Depends on lens used
Recording
RAW Recording options
RAW (Cinema RAW Light)
Internal Recording
Cinema RAW Light, MP4
Recording time (CFast 2.0TMcard)
128GB card 15 Mins (4K Cinema RAW Light 1Gbps VBR)
Recording time (SD Card)
128GB card 110 mins (MP4, 150Mbps) 485Mins (MP4, 35Mbps)
Recording Formats
Cinema RAW Light, (CFast 2.0TM1) MP4 XF-AVC (SD card. XF-AVC2)
Recording Frame Rate
(1) 59.94 Hz mode (59.94P/29.97P/23.98P) (2) 50.00 Hz mode (50.00P/25.00P)
(3) 24.00 Hz mode (24.00P)Slow/Fast motion
YES
Interval Record
YES
Frame Record
YES
Pre Record (cache record)
YES, 3 seconds
Relay Recording
YES, SD Card recording only
Double Slot (simultaneous) Recording
YES, SD Card recording only
Scan Reverse
NO
HD->SD conversion
NO
Photo storage media
SD Card
Photo Recording Size
2048x1080 (when video image resolution is 4096x2160/2048x1080) 3840x2160 (when video image resolution is 3840x2160)
1920x1080 (when video image resolution is 1920x1080)System
Wave Form Monitor
YES
Colour Bars
YES, SMPTE / EBU / ARIB
Peaking
YES
Zebra
YES. Zebra 1 Level 5 ±5% to 95 ±5% in 5 percentage point intervals (70 ±5%) Zebra 2 Level: 0% to 100% in 5 percentage point intervals (100%)
Markers
YES, Centre, Horizontal, Grid Aspect Ratio(4:3 / 13:9 / 14:9 / 16:9 / 1.375:1 / 1.66:1 / 1.75:1/1.85:1 / 1.90:1 / 2.35:1 / 2.39:1 / Custom), Safe Area (80% / 90% / 92.5% / 95%)
EVF
Built- In EVF
YES. 1.77M dots
Optional EVF Accessory
Canon EVF-V70 (Also requires CL-V2 bracket)
Display Panel
Display Panel
4 inch/10.1cm diagonal LCD Monitor. Touch panel. Approx., 1.23M dots
Inputs/Outputs
Audio in
XLR x2, 3.5mm Audio, AES/EBU digital or Analog Audio input, Line, Mic, +48V Phantom Power supported
Headphone output
YES
HDMI
YES, HDMI 2.0, output only. Max. output resolution 3840 x 2160.Timecode out compatible
USB
YES. Mini-B Hi-Speed USB
3G/HD-SDI output
YES x 1.BNC jack
Video [HD]:SMPTE 292. [3G]:SMPTE 424, SMPTE 425
Audio [HD]:SMPTE ST 299-1. [3G]:SMPTE ST 299-2, Output impedance 75 Ω, Output signal level 0.8 Vp-pTime code
NO
Genlock
NO
Synch
NO
Component out
NO
AV terminal
NO
DC Output
NO
DC input
YES, 14.4V DC (Battery), 16.7V DC (DC-In)
Power Consumption
50.00P: Cinema RAW Light/MP4; 18.5W (Approx.)
Continuous Recording Time (battery)
BP-A30 (3100mAh) 130 Min (Approx.) BP-A60 (6200mAh) 280 Mins (Approx.) Cinema Raw Light/4096 x 2160 or MP4/3840 x 2160 recording
Remote Control Terminal
YES, 2.5mm proprietary connector
Wireless Control Terminal
Built-in Wi-Fi. FTP and Browser Remote/Preview
Lens terminal
NO
Ethernet terminal
YES. FTP CAPABLE, MP4 files only
Video connector (For Monitor or EVF)
YES, Canon proprietary connection
Misc.
Tally lamp
YES
Custom Dial
YES
Shooting functions
Exposure
Exposure metering
(a) Standard (centre-weighted metering) (b) Spotlight
(c) Backlight (compensation)Exposure compensation
AE shift function . The target value (±8 steps from centre) for the
brightness can be set. Indicated as exposure values (EV). (±2.0, ±1.75,
±1.5, ±1.25, ±1.0, ±0.75, ±0.5, ±0.25, and ±0) are displayed on the screen as AE [numerical values]Push Auto Iris
YES
Exposure Lock
NO
Auto Gain Control setting
NO
ISO Sensitivity
1-Stop Display: [100], 160(*), 200, 400, 800, 1600, 3200, 6400, 12800, 25600, [51200,102400]
[---] Displayed when ISO speed expansion is ON. (*) Displayed when ISO speed expansion is OFF.1/3 Stop Display: [100,125], 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000, 25600, [32000, 40000, 51200, 64000, 80000, 102400] [---] When ISO speed expansion is ON.Gain setting
[-6dB,-3dB], -2dB(*), 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB, 39dB, 42dB, [45dB, 48dB, 51dB, 54dB]
[---] Displayed when ISO speed expansion is ON. (*) Displayed when ISO speed expansion is OFF.When ISO speed expansion is ON: between -2 dB and 54 dB
When ISO speed expansion is OFF: Any value from -2 dB to 42 dB in 0.5 dB increments can be set.Auto Focus System
Dual Pixel CMOS AF supported
Manual focus, one-shot AF, continuous AF, AF-Boosted MF,
face detection AF (only lenses that support AF functions can be used in any of these modes), focus guideAF Frame Sizes
Large; size equivalent to approx. 20% (vertical) x 25% (horizontal) of the image display range; Small; size equivalent to approx. 20% (vertical) x 8% (horizontal) of the image display range
Auto Focus Modes
One-Shot AF, Continuous AF and AF-Boosted MF are the available modes. All of these modes take effect when the AF/MF switch of the EF lens is at the AF setting.
One-Shot AF: AF is performed only while the one-shot button to which it has been assigned is helddown. No further lens movement is permitted after focusing. Continuous AF: AF control is performed at all times. AF-Boosted MF
Face Detection AF
Available; face Priority or Face Only.
Face Priority: AF is set to face frame when a face is detected, to tracking frame when tracking, and AF frame when there is no face or tracking.
Face Only: Switches to face frame when a face is detected, to tracking frame when tracking, and MF when there is no face or tracking.
In both Face Priority and Face Only, the face to detect can be selected with the joystick.Focus Guide
Available; displays focus status or unfocused status using the AF signal.
Shutter speed
Control Modes
Manual only
Shutter speed
1/3 stop display: 1/1, 1/1.26, 1/1.59, ---, 1/1600, 1/2000 (total of 34 settings)
1/4 stop display: 1/1, 1/1.19, 1/1.41, 1.68 ---, 1/1700, 1/2000 (total of 45 settings). The slowest speed will differ depending on the frame rate setting.Shutter Angle
360.00, 240.00, 180.00, 120.00, 90.00, 60.00, 45.00, 30.00, 22.50, 15.00, 11.25
Also, angle values equivalent to 1/120, 1/60, 1/40, 1/30, 1/100, 1/50, 3/100, and 1/25 are selectable within the minimum angle range from 360°.Slow Shutter (SLS)
59.94(i/P) : 1/4, 1/8, 1/15, 1/30
29.97P frame rate has been set: 1/4, 1/8, 1/1524.00P or 23.98P: 1/3, 1/6, 1/12
Clear Scan
24.00 Hz* to 250.40 Hz
(*) The frequency will differ depending on the frame rate setting.Custom Picture
Stored Configurations
PRESET: Canon Log 3/Canon Log /BT.709/Off
GAMMA: Canon Log 3/Canon Log/Wide DR/Normal 1 (Standard)/Normal 2 (x4.0)/Normal 3(BT.709)/Normal 4 (x5.0)
COLOUR MATRIX: Neutral/Production Camera/Cinema EOS/Original /Video/ OffStorage Medium
Internal, SD Card
Master Pedestal
0 ± 50
Master Black Red
0 ± 50
Master Black Green
0 ± 50
Master Black Blue
0 ± 50
Black Gamma
0 ± 50
Low Key Saturation
0 ± 50
Knee Point
+ 50 - 95 - +109
Knee Slope
-35 - 0 - +50
Knee Saturation
0 - ±10
Sharpness Level
-10 - 0 - +50
Noise reduction
Off / 1 - 12
White balance Red/Blue Gain
0 - +50
Setup level
(0 - ±50)
Wi-Fi & GPS Specifications
GPS Information (Optional Accessory)
Location (latitude, longitude and altitude) and GPS information using Coordinated Universal Time (UTC) can be added to RAW movies, MP4 movies and photos. Satellite data acquisition status can be checked in camera mode.
W-Fi Specification
Standard: IEEE 802.11b/g/n (2.4 GHz band), IEEE 802.11a/n (5 GHz band) (not supported in Qatar, Indonesia or Iraq) IEEE 802.11b/g/n (2.4 GHz band) IEEE 802.11n/11a (5 GHz band): Differs depending on the model’s destination.
Authentication: Open system, WPA-PSK, WPA2-PSKEncryption systems: WEP-64, WEP-128, TKIP, AES
White balance
Auto
YES. Shockless WB available
Preset
Daylight (5600K), Tungsten (3200K)
Manual Setting
Preset A/B, Colour Temperature Setting: 2000K - 15000K
Black balance
Black balance adjustment
Auto Black Balance Adjustment
Time code
Countup system
Regen, RecRun, FreeRun, TC Hold. Drop Frame /NonDrop Frame ( DF/NDF) in 59.94P/29.97P mode only
Audio
Recording
Cinema RAW Recording: Linear PCM: 16-bit / 48 kHz / 4 channels
MP4: MPEG-4 AAC-LC (16-bit / 48 kHz / 2 channels), Linear PCM (16-bit / 48 kHz / 4 channels)Accessories
Supplied
LCD Monitor LM-V1 , LCD Attachment Unit LA-V1, Handle Unit HDU-2, Mic holder unit, Thumb rest, Eyecup, Shoulder strap (SS-1200), Battery Charger CG-A20,
Compact Power Adapter, CA-CP200B, AC Adapter CA-A10, AC cable x 2, Ferrite core, Battery pack (BP-A30) ,Unit Cable UN-5 , Allen wrench, boltsOptional
Canon Battery Pack BP-A30 (provided with camera)/BP-A60 Canon Battery Charger CG-A10/ CG-A20
Canon LCD Monitor LM-V1
Canon LCD Attachment Unit LA-V1Canon Clamp Base CL-V2
Canon Camera Grip GR-V1
Canon Handle Unit HDU-2
Canon OLED Electronic View Finder EVF-V70 Canon Shoulder Support Unit SU-15Canon Rod Clamp RD-1
Canon AC Adapter CA-A10
Canon Compact Power Adapter CA-CP200B Canon Unit Cable UN-5/UN-10
Canon Remote Controller RC-V100
Canon GPS Receiver GP-E2
Canon Shoulder Strap SS-1200
Canon EF lenses, EF cinema lenses (EF mount)Miscellaneous
Dimensions (Main Body Only)
Approx. 144 x 153 x 179 mm (5.7 x 6.0 x 7.0 in)
Approx. 178 x 153 x 204 mm (7.0 x 6.0 x 8.0 in) [With camera grip attached]Weight (Body Only)
Approx. 1430g (3.2lb)
Weight ( Supplied Accessories)
Camera Grip GR-V1: Approx.260 g (9.2 oz.)
LCD Monitor LM-V1: Approx. 185 g (6.5 oz.)
LCD Attachment Unit LA-V1: Approx. 255 g (9.0 oz.) Mic holder unit: Approx. 50 g (1.8 oz.) Handle Unit HDU-2: Approx. 220 g (7.8 oz.)
Hex Socket Head Bolt:Approx. 5 g (0.18oz.)
BP-A30: Approx. 225 g (7.9 oz.)Unit Cable
UN-5: Approx. 80 g (2.8 oz.)
Thumb rest: Approx. 10 g (0.35 oz.)
Eyecup: Approx. 25 g (0.88 oz.)Operating Temperature range
Approx. 0 to 40°C, 85% (relative humidity) Approx. -5 to 45°C, 60% (relative humidity)
